CHASERVO HV95
€63,96
| Brand | Chaservo |
|---|---|
| Dimensions | 1.18 x 0.37 x 1.31 in (30 x 9.5 x 33.5 mm) |
| Weight | 0.76 oz (21.7 g) |
| Output Shaft Spline | 25T, 0.236 in (6 mm) |
| Rated Voltage | DC 7.4V |
| Voltage Range | DC 4.8 – 8.4V |
| Holding Torque @ 6.0V | 118.0 oz·in (8.5 kg·cm) |
| Holding Torque @ 7.4V | 145.81 oz·in (10.5 kg·cm) |
| Holding Torque @ 8.4V | 159.7 oz·in (11.5 kg·cm) |
| Output Torque @ 6.0V | 104.1 oz·in (7.5 kg·cm) |
| Output Torque @ 7.4V | 9.3 kg·cm |
| Output Torque @ 8.4V | 141.6 oz·in (10.2 kg·cm) |
| No-load Speed @ 6.0V | 0.17sec/60° |
| No-load Speed @ 7.4V | 0.15sec/60° |
| No-load Speed @ 8.4V | 0.12sec/60° |
| max. Current @ 6.0V | 1.16 A |
| max. Current @ 7.4V | 1.32 A |
| max. Current @ 8.4V | 1.58 A |
| Case Material | Aluminium |
| Gear Set Material | Metallgetriebe |
| Ball Bearing | 2 x Ball Bearing |
| Position sensor | Potentiometer |
| Motor | Coreless DC |
| Working Frequency | 1520µs/333Hz |
| Pulse Range | 500 μs – 2500 μs |
| Programmable | Ja |
